Car GPS Tracker Waterproof IP65 5000mAh Truck Car Locator TKSTAR TK905 90 Days Standby Powerful Magnet Lifetime Free APP Web Details & Specification :

Item Specifications
Brand Name prazata
Item Size 90mm * 72mm * 22mm
Screen Size Under 2 Inches
Voltage 12V
Out Power W
Special Feature Waterproof
GPS type GPS Tracker
GPS Geographic Location Europe
Battery Life 30 Hours & Up
Gps Module Yes
Model Name TK905
Warranty One year
Band GSM/GPRS 850/900/1800/1900Mhz
GPS Main Unit Weight 168g
GPS Accuracy 5m
Waterproof IP65
Web&APP Tracking Life Time Free
Battery Chargeable 3.7V 5000mAh Li-ion
Standby Time Around 90 Days
Magnet Support
Other Features Geofence/Voice Monitor/6 Months History Route Playback/Movement Alarm

16 17



This product TK905 is a 2G GSM GPS Tracker which is working based on the existing 2G GSM/GPRS network and GPS satellites, it can locate and monitor any targets remotely by SMS, mobile APP and web tracking software!

It adopts the most advanced technology of GPS and LBS dual positioning. Besides, with built-in powerful magnet, it can be installed very easily and tightly on car, truck and any target with metal interface.

What's more, it supports GSM Quad Band Frequency(850/900/1800/1900Mhz), can work perfectly around the worldwide!


1. GPS+LBS Dual Positioning Ways:
If the gps signal is good, the device will locate via gps satellite, if not, the device will locate via LBS! Under GPS locating mode, the accuracy is 5-10 meters, under LBS locating mode, the accuracy is 100-1000 meters!

2. Realtime Tracking: You will can realtime track the device on google maps via mobilephone, tablet and computer, and the minumum data upload interval is 10 seconds!

History Route Playback: The APP and web server can record the upload data of the device up to 6 months, you will can playback the history route at any time!
4. Long Standby Time: It has built-in 3.7V 5000mAh Li-ion battery, can standby up to 90 days.
5. Powerful Magnetic: It has 5pcs built-in magnets,with super strong powerful magnetic,can be very easily installed.

6. Waterproof: The waterproof level of this device is IP65, it can resist splash water but can't be put under water!
7. Remotely Voice Monitor: Send "Monitor+Password" to the device first, then the device will turn into monitor mode,
now if you make call to the SIM number in the device, it will pick up your call automatically and you will can monitor the voice around the device!
8. Overspeed Alarm: This alarm works only under continuous positioning mode.When the unit speed is exceed the speed you presetted, it will send message “speed alarm!” to the admin number every 5 minutes.
9. Shake Alarm: After you did the shake alarm setting,please keep the tracker being stationary for 5 minutes, then this function will start working. It will send SMS “sensor alarm!” to the admin number when the unit get shocked.

10. Movement Alarm: When the units stays immobile in a place for 10 minutes, the user can set up the movement alarm by this command "move+passord", then in case the device moved 500m it will send alarm SMS "Move Alarm+Latitude and longitude" to the authorized number.

11. Geofence:
Set up a geofence for the tracker to restrict its movements within a district. The unit will send alarm information to APP and web server when it goes out of or get in this district.
12. Sleep Mode for Saving Battery:
* Sleep by time mode: After did this setting, tracker will only work for 5 minutes after being waked up, and back to sleep mode, GPS will shut off and GSM will works in low consumption mode. SMS, call will can wake up the tracker.
* Sleep by shock sensor mode: After did this setting, if no shock for 5 minutes, the tracker will work under "sleep by shock" mode, GPS will shut off, GSM will works in low consumption. Vibration, SMS, call will can wake up the tracker.
* Dim: 90mm * 72mm * 22mm (3.54" * 2.83" * 0.87")
* Weight: 168g
* Network: 2G GSM/GPRS
* Band: 850/900/1800/1900Mhz
* GPS chipset: u-blox UBX-G7020
* GPS sensitivity: -159dBm
* GPS accuracy: 5m
* Wall charger: 110-220V  input  5V-1A  output
* Battery: Chargeable 3.7V 5000mAh Li-ion battery
* Stand by time: 90days
* Storage Temp.: -40°C to +85°C
* Operation Temp.: -20°C to +55°C
* Humidit: 5%--95% non-condensing


Lifetime Free Web tracking platform :

Web tracking platform: ,  Select " Log in by IMEI " on the bottom of screen
IMEI No. : on the back side of cover
Default password: 123456

Lifetime Free Mobile APP Tracking:

Search "TKSTAR GPS" in the Apple App Store/Google Play Store or Scan the QR Code to install  the applications on your cell phone.

1 * TK905 Main Unit
1 * Carry Bag
1 * Nano SIM Card Adapter
1 * Micro SIM Adapter
1 * Eject PIN
1 * User Guide
1 * Charging Cable
1 * Genuine Box (Optional)
1 * Hard-wired Car Charger (Optional)
